Description
These Eaton switches covered by this Component Maintenance Manual are designed to be used in any fluid that is compatible with stainless steel or aluminum. The design incorporates a snap-action electrical microswitch which is actuated by a piston-sensing element.
They are designed to be used in any fluid that is compatible with stainless steel or aluminum. The design incorporates a snap-action electrical microswitch which is actuated by a piston-sensing element.
A snap-action belleville spring system employing a negative rate resists movement until actuation pressure is achieved. The spring then 'snaps' through and microswitch actuation occurs. This process is reversed for deactuation. The snap-action spring design is very reliable and has excellent vibration and shock resistance. A positive-rate bellevelle stack is also available for tighter set-point tolerance.
For use with hydraulic oils and other select fluids.
Suitable for
- Pump cutoff
- Timer operations
- Low or High pressure
- Miscellaneous hydraulic sensing needs
NOTE Switch image is typical - different body and connectors are used according to the intended end-installation
