brand logo Block - Multi-purpose Lead Deck Single Plain - Barton - High Load - 82200

Modern block of bolt together construction for easy servicing

Block - Multi-purpose Lead Deck Single Plain - Barton - High Load - 82200
Primary material composition Aluminium alloyStainless steel
Sheave diameter 1.97 in / 50 mm2.56 in / 65 mm3.35 in / 85 mm
Rope/line diameter 12 mm16 mm18 mm
Primary method of attachment Shackle wire reversed removableSide faceSide face - Cam cleatSwivel, Shackle wire reversed removable

Description

Manufactured from marine grade aluminium and 'Spectro' grey anodised for high ultraviolet light stability and durability

Sheave is precision turned from solid Ertalyte bar with a profile that is kind to modern ropes

This block has a multitude of uses es

Product Detail

item
Item type Block
Item type variant Lead deck
Item type variant detail Multi-purpose
identity
Primary identity code for a product or service 82200
Product brand Barton
Product model High load
material
Primary material simple composition Aluminium
Primary material composition Aluminium alloy
Secondary material simple composition Stainless/SS
Secondary material composition SAE/AISI 316 EN 1.4401 A4 stainless
Sheave material composition Ertalyte
Bearing composition Stainless steel
measurement
Overall length 5.59 in
142 mm
Width of sheave or pulley 0.709 in
18 mm
Rope/line diameter 16 mm
Sheave diameter 2.56 in
65 mm
Nett weight 0.267 kg
0.589 lb
mechanical
Average breaking force 1569 daN
1600 kg
3527 lb
Maximum safe working force 785 daN
800 kg
1763 lb
construction
Rope type Polyester
Sheave count Single
Type of bearing Plain
arrangement
Primary method of attachment Swivel
Shackle wire reversed removable
applicable vessel
Types of use Control line sportboats
Control line dinghy/dinghies
Sheet spin/asym yacht race
Sheet spin/asym yacht
Control line yacht race
Control line yacht
Leads
Type of boat Dinghies/Sportsboats racing
Cruiser medium
appearance
Primary colour name Charcoal
Primary colour Grey
translation
Item class in Danish Yacht blok
Item class in Dutch Yacht blok
Item class in French Voilier poulie
Item class in German Yacht-Block
Item class in Italian Yacht di blocco
Item class in Norwegian Yacht blokk
Item class in Portuguese bloco Yacht
Item class in Spanish Yacht bloque
Item class in Turkish Yat blok
Item class in Swedish Baten blocket
